Design and Verification of an SPI-Wishbone Controller
Corressponding author's email:
tandd@hcmute.edu.vnDOI:
https://doi.org/10.54644/jte.71B.2022.1142Keywords:
SPI standard, Wishbone bus, FPGA, Verilog, TestbenchAbstract
SPI (Serial Peripheral Interface) is a synchronous serial communication standard for connecting and transferring data between electronic devices proposed and developed by Motorola Inc. The main advantages of SPI standard are high data transmission speed, synchronization, simple connection, and low logic resources. Furthermore, Wishbone is a popular bus standard with open source codes, widely used in Silicore Corporation's projects. In this paper, we present a detailed design of a controller called SPI-Wishbone, which communicates with peripheral devices based on the SPI standard that can be configured in either Master mode or Slave mode. The designed module can be controlled, transmit, and receive data from a central processing unit via Wishbone bus. Finally, we conduct extensive simulation results and a summary of logic resource usage and power consumption to validate the functionality and effectiveness of the proposed design. We use Verilog Hardware Description Language in the design and simulation processes of the SPI-Wishbone module.
Downloads: 0
References
G. Sung, L. Tung, H. Wang and J. Lin, "USB Transceiver With a Serial Interface Engine and FIFO Queue for Efficient FPGA-to-FPGA Communication," in IEEE Access, vol. 8, pp. 69788-69799, 2020. DOI: https://doi.org/10.1109/ACCESS.2020.2986510
I. I. b. Jamaludin and H. b. Hassan, "Design and Analysis of Serial Peripheral Interface for Automotive Controller," 2020 IEEE Student Conference on Research and Development (SCOReD), 2020, pp. 498-501. DOI: https://doi.org/10.1109/SCOReD50371.2020.9250981
Anand N, G. Joseph, S. S. Oommen and R. Dhanabal, "Design and implementation of a high speed Serial Peripheral Interface," 2014 International Conference on Advances in Electrical Engineering (ICAEE), 2014, pp. 1-3. DOI: https://doi.org/10.1109/ICAEE.2014.6838431
M. Koushik, R. Anushree, B. J. Sowmya and N. Geethanjali, "Design of SPI Protocol with DO-254 Compliance for Low Power Applications," 2017 International Conference on Recent Advances in Electronics and Communication Technology (ICRAECT), 2017, pp. 186-190. DOI: https://doi.org/10.1109/ICRAECT.2017.45
D. Trivedi, A. Khade, K. Jain and R. Jadhav, "SPI to I2C Protocol Conversion Using Verilog," 2018 Fourth International Conference on Computing Communication Control and Automation (ICCUBEA), 2018, pp. 1-4. DOI: https://doi.org/10.1109/ICCUBEA.2018.8697415
A. K. Oudjida, M. L. Berrandjia, A. Liacha, R. Tiar, K. Tahraoui and Y. N. Alhoumays, "Design and test of general-purpose SPI Master/Slave IPs on OPB bus," 2010 7th International Multi- Conference on Systems, Signals and Devices, 2010, pp. 1-6. DOI: https://doi.org/10.1109/SSD.2010.5585592
M. Hafeez and A. Saparon, "IP Core of Serial Peripheral Interface (SPI) with AMBA APB Interface," 2019 IEEE 9th Symposium on Computer Applications & Industrial Electronics (ISCAIE), 2019, pp. 55-59. DOI: https://doi.org/10.1109/ISCAIE.2019.8743871
B. Zhou, D. Li and G. Lu, "Design of high-speed and reusable SPI IP core based on Wishbone interface," 2011 International Conference on Electrical and Control Engineering, 2011, pp. 1040-1042. DOI: https://doi.org/10.1109/ICECENG.2011.6058000
J. Yang, Y. Xiao, D. Li, Z. Li, Z. Chen and P. Wan, "A Configurable SPI Interface Based on APB Bus," 2020 IEEE 14th International Conference on Anti-counterfeiting, Security, and Identification (ASID), 2020, pp. 73-76. DOI: https://doi.org/10.1109/ASID50160.2020.9271704
Ngoc P.T., Bao H.N., Tan D.D., Phuc T.Q., Ca P.V., "A novel multichannel UART design with FPGA-based implementation", International Journal of Computer Applications in Technology, vol. 67, no. 4, pp 358–369, 2022. DOI: https://doi.org/10.1504/IJCAT.2021.10046400
Richard Herveille, WISHBONE System-on-Chip (SoC) Interconnection Architecture for Portable IP Cores, rev. version: B4, Open Cores Organization, p.7, 2010. www.opencores.org
C. Dongye, "Design of the on-chip bus based on Wishbone," 2011 International Conference on Electronics, Communications and Control (ICECC), 2011, pp. 3653-3656. DOI: https://doi.org/10.1109/ICECC.2011.6067598
